2012 TEREX Quadstar 1100

2012 TEREX Quadstar 1100

$329,000 (USD)

Location:Green Bay, Wi

orCall 1 (833) 776 9937

Description

2012 Terex RT110 Rough Terrain Crane, 5,483 hours, #30,000 counterweight and Jib is included but not shown in photos. Well maintained and needs nothing. Boom Min Operating Radius 7.16ft in, Max Elevating Angle 80degrees, Transport Length 47.64ft in, Transport Width 11.52ft in, Transport Height 13.33ft in, Wheelbase 172.05in, Ground Clearance 1.81ft in, Width W/ Outriggers Extended 25.96ft in, Carrier/Base Length 27132.55ft in, Upper Structure Tail Swing Radius 13.82ft in, 6 Cylinders, Engine Make Cummins QSB, Engine Model C6.6, Emissions Compliance Tier 4F / Stage IV, Gross Power 270hp, Power Measured @ 2000rpm, Max Torque 730.2lb ft, Torque Measured @ 1500rpm, Displacement 408.9cu in, Bore 4.3in, Stroke 4.9in, Crankcase Capacity 14.2 L, Operational Def Tank Capacity 5gal, Operating Weight 87534.6lb, Fuel Capacity 75gal, Hydraulic System Fluid Capacity 153gal, Operating Voltage 12V, Alternator Supplied Amperage 190amps, Tire Size 29.5 x 25, Transmission Transmission Type Powershift, Number Of Forward Gears 6, Number Of Reverse Gears 6, Max Speed - Forward 18.6mph, Max Speed - Reverse 18.6mph.

Specifications

ManufacturerTEREX
ModelQuadstar 1100
Year2012
ConditionUsed
Stock NumberTOT0AJAU258670
Hours5483
